This Dual LCD monitor mount is designed for mounting two larger LCD monitors back to back on a floor or ceiling mounted pole system. Each monitor is mounted to a tilter head allowing for full tilt and 360° rotation with ease. The tilter heads also enable independent instant landscape to portrait adjustment for the two monitors. Optional extensions can add up to 10 inches of reach and two more articulation points to each side of the mount. This heavy-duty mount ideally suited for most flat panel monitors and compatible with Ergomart's 192 Series Pole Systems, and in particular the 192 Center Pole Stand and the 192 Flange Pole Mount.
Optional Extensions Increase Reach of the PM42 LCD Pole Mount: The 3.5 inch extension has a final weight capacity of 39 lb; the 7 inch extension will handle 35 lb; 10.5 inch extension (3.5 + 7 inch) will handle 30 lb payloads.
Our monitor pole mounts can handle larger monitor sizes with the Adjustable MSU4X6 VESA adapter, which can fit any VESA hole pattern between 100mm (height) x 300mm (width) and 400mm (height) x 600mm (width). Note that the MSU4x6 is only recommended with the heavy duty spring tilter head and without any horizontal extensions. The weight of the MSU4x6 is 9 pounds and must be added to that of the monitor to determine the suitability of the mounting solution.
|Shipping Weight||12 pounds|
|23 pounds (with one MSU4x6 VESA adapter)|
|32 pounds (with two MSU4x6 VESA adapters)|
|Shipping Dimensions||10" x 8" x 6"|
|27" x 16" x 9" (with one MSU4x6 VESA adapter)|
|30" x 30" x 6" (with two MSU4x6 VESA adapters)|
|Warranty||3 year limited|
The screen can rotate 360° on the tilter head allowing the user to switch from portrait to landscape with ease.
With the two 7'' extensions, the horizontal arm can be extended up to 18.25'' from the pole.
The direction of the monitor can be changed by rotating the tilter horizontally within it's range, allowing viewing from different angles.
The monitor can be adjusted 90° upward and 45° downward with respect to the vertical orientation, allowing the user to select the most comfortable viewing angle.
Side view of PM42 Back-to-Back Pole Mount with two standard tilters. A 1.5 to 2 inch outside diameter vertical pole supports this assembly.
Top view of PM42 Back-to-Back Pole Mount with standard tilter. 10 inch distance between opposite VESA mount brackets will vary slighly depending on the pole diameter.
Side view of the PM42 shows the height of the yoke at 2.5 inches and the overall 4.5 inch height of the assembly including the monitor tilter mechanism
3.5" Straight Extension Arm. Overall body length is 5 inches while the net extension is 3.5 inches
PM42 with the 3.5-inch Straight Extension Arm. The PM42 with a 3.5 inch extension has a final weight capacity of 39 pounds per arm. Select the correct monitor tilter for heavier payloads.
PM42 with the 7-inch Straight Extension Arm. The PM42 with a 7 inch extension has a final weight capacity of 35 pounds per monitor tilter head. Select the correct monitor tilter for heavier payloads.
PM42 with the 7 inch Straight Extension Arm. The PM42 with a 7 inch extension has a final weight capacity of 35 pounds. Select the correct monitor tilter for heavier payloads.
Two 3.5" sections extend the reach of the mount by 7" and provide an additional point of articulation which allows the monitor tilter mechanism to fold back to the center.
PM42 with the 7-inch Articulated Extension Arm. This configuration has a final weight capacity of 35 pounds per arm. Select the correct monitor tilter for heavier payloads.
The 7" and 3.5" sections extend the reach of the mount by a total of 10" and provide an additional point of articulation.
PM42 Pole Mount with the 10-inch Articulated Extension Arm. This configuration has a final weight capacity of 30 pounds per arm. Select the correct monitor tilter for heavier payloads.
This large VESA bracket is intended for mounting a monitor or TV with a 200x200 mm, 100x200 mm, or 120x180 mm hole pattern. The central hole patterns are 50x50 mm, 75x75 mm, and 100x100 mm, enabling this bracket to attach to the mounting location (e.g. an Ergomart Tilter Head) using a VESA 75/100 adaptor.
The large 200x400 mm VESA adaptor plate supports 50 mm, 75 mm, 100 mm and 200 mm square patterns, as well as 100x200 mm, 120x180 mm, 200x300 mm and 200x400 mm rectangular patterns. In some cases an additional 75 or 100 mm VESA adaptor is needed to interface the 200 x 400 mm VESA plate to the mounting location.
This VESA 1/4-Inch Spacer Kit allows monitors with VESA hole locations that are recessed by 1/4" or less to be attached to an Ergomart VESA plate.
This VESA 1/2-Inch Spacer Kit allows monitors with VESA hole locations that are recessed by 1/2" or less to be attached to an Ergomart VESA plate.
