CONNECT-22 monitor mount with single central stand with two beams mounted vertically supporting a total of four monitors inwardly oriented
Connect-22 Dual Tier Quad Monitor Stand

In stock

From $535.68

Increase Down Increase Up

Texas Tax-Exempt Customers:

Please select REQUEST QUOTE

Usually ships in 3-7 business days.


Need a mounting option not listed here? Call (888) 420-3200 or visit our

Custom Solutions page.

Connect-22 Dual Tier Quad Monitor Stand


The motorized version is available in limited quantities. Please contact us if you need multiple units.

Please wait while your content is loading.



  • Connect-22 is our popular highly adjustable stand for holding 4 monitors in a square configuration each up to 28.5” wide (flat alignment)
  • When monitors are curved inward, the max width is approximately 27”
  • Top quality components offer maximum flexibility in monitor positioning
  • Available with powered column providing 10 inches of height adjustment
  • Offered with thru-desk or clamp mounting options
  • Smart, clutter-free cable management
  • Modular, scalable design allows upgrading to six or eight monitors with maximal reuse

The CONNECT-22 is a dual-tier stand designed to handle four monitors each measuring 28.5 inches wide and weighing as much as 30 pounds each. Two, sturdy, functional horizontal beams can be mounted at any height along the 33 inch tall central column. The four monitors are installed on premium articulating VESA mounts which can be located anywhere along the beams. These tilter mechanisms provide instant landscape/portrait orientation adjustment, as well as full swivel and tilt capability. The wire management system resides along the column and the beams and ensures clutter-free cable routing. The stand is attached to the work surface via either a thru-desk or a clamp mount assembly.

The CONNECT system is highly modular and can scale from 2 to 8 monitors, including some asymmetrical configurations, all the while reusing the original parts of the mounting system. The flexibility inherent in this design philosophy makes the CONNECT the smart choice for those who anticipate that their computing needs will evolve over time.

Motorized Height Adjustment

The CONNECT-22 dual-tier, four monitor stand comes with an optional motorized column which provides up to 10 inches of simultaneous vertical adjustment to all four monitors at the touch of a button, accommodating stations where multiple users of different heights alternate. The motorized column can move a total weight of about 150 pounds. Accounting for the weights of the system components, the maximum per-monitor weight for the Motorized Height-Adjustable Connect-22 is 29 lbs.

Connect-22 Shipping Weights and Dimensions
Static Column 39 lb, 41"x15"x15"
Motorized Column box1: 20 lb, 40"x13"x6", box2&3: 14 lb, 32"x15"x4"
Clamp Mount adds 7 lb to box1

Mount Type

Quad Monitor Desktop Stand

Number of Monitors



Through Desk Mount Clamp Mount Rail Mount

Weight Range

up to 30 lbs per monitor

Monitor Horizontal Reach

8.5" mount to monitor in flat setup

Vertical Adjustment

Readjustable along 33.5" column

Vertical Extensions

Call for information.

VESA Options

75 x 75
100 x 100
Call for additional VESA sizes

Portrait to Landscape


Max Swivel (at Monitor)

Up to 90° depending on monitor size/tilt

Monitor Tilt Range

+90° up, -45° down


CONNECT-22 Specification drawing shows standard dual beams and four tilter mechanisms monitor stand perspective view

Monitors are placed in a dual-tier, two-over-two configuration. Each row contains one 30 inch beam with two fully articulating monitor mounts called tilter mechanisms or tilter heads.



CONNECT-22 Specification drawing of standard double vertical column side and perspective view for mounting multiple monitors

Static columns are used to mount the horizontal beams. Each beam can be placed anywhere along the column during installation. The Dual static column is 33.5 inches in height.



CONNECT-22 Specification drawing illustrates vertical travel and positioning of optional electric lift column used with monitor mounting beams

The motorized column is an optional feature. It enables up to 10 inches of simultaneous height adjustment for both monitors when the button located at the base is pressed.



CONNECT-22 Specification drawing illustrates the maximum width between 2 VESA brackets on dual monitor beams

The dual monitor setup places the two tilter mechanisms side by side anywhere along a 30 inch horizontal beam. In this configuration, the CONNECT-22 can accommodate monitors that each measure up to 28.5 inches wide in landscape orientation.



CONNECT-22 Specification drawing shows standard dual monitor beam illustrating widest possible screens side by side

The two-tier four monitor stand CONNECT-22 allows the maximum width of each monitor to be approximately 28.5 inches when they are in a flat alignment.



CONNECT-22 Specification drawing shows standard quad monitor stand top view with screens angled maximally inward

Many users like to have their monitors curved inwards. Angling the monitors of the two-tier CONNECT-22 inwards slightly reduces the maximum allowable width from 28.5 inches to around 27 inches compared to a flat configuration (assuming a 2 inch deep monitor).



CONNECT-22 Specification drawing illustrates depths of components from side view Connect system

The side view of the single tier configuration with the clamp mount assembly and the tilter mechanism show that the depth of the stand before the monitor is placed is 8.5 inches.


100x200mm Flat VESA Plate with Hardware
100x200mm Flat VESA Plate with Hardware


The 100 x 200 mm VESA adaptor is compatible with certain larger monitors. It is used to attach the monitor to an Ergomart tilter head, present in all SAA, SA, and LS arms and mounts. If your monitor has a recessed VESA attachment point, you may also need an Ergomart VESA spacer kit, available below in the accessories tab.

200x200mm Flat VESA Plate with Hardware
200x200mm Flat VESA Plate with Hardware

This large VESA bracket is intended for mounting a monitor or TV with a 200x200 mm, 100x200 mm, or 120x180 mm hole pattern. The central hole patterns are 50x50 mm, 75x75 mm, and 100x100 mm, enabling this bracket to attach to the mounting location (e.g. an Ergomart Tilter Head) using a VESA 75/100 adaptor.

200x400mm Flat VESA Plate with Hardware
200x400mm Flat VESA Plate with Hardware

The large 200x400 mm VESA adaptor plate supports 50 mm, 75 mm, 100 mm and 200 mm square patterns, as well as 100x200 mm, 120x180 mm, 200x300 mm and 200x400 mm rectangular patterns. In some cases an additional 75 or 100 mm VESA adaptor is needed to interface the 200 x 400 mm VESA plate to the mounting location.

Heavy-Duty Mount Adapter Plate 100x300 to 400x600mm
Heavy-Duty Mount Adapter Plate 100x300 to 400x600mm

The extra large MSU4X6 VESA adaptor bracket attaches to a wide range of VESA patterns from 100x300 mm up to 400x600 mm. The hole patterns on the central plate allow it to be mounted to tilter heads or wall mounts, often using an additional smaller VESA plate (e.g., 75 mm, 90 mm, 100 mm, 200 mm or 100x200 mm) in between.

VESA 1/4-inch Spacer Kit
VESA 1/4-inch Spacer Kit

This VESA 1/4-Inch Spacer Kit allows monitors with VESA hole locations that are recessed by 1/4" or less to be attached to an Ergomart VESA plate.

VESA 1/2-inch Spacer Kit
VESA 1/2-inch Spacer Kit

This VESA 1/2-Inch Spacer Kit allows monitors with VESA hole locations that are recessed by 1/2" or less to be attached to an Ergomart VESA plate.

Leave a Review
You're reviewing:Connect-22 Dual Tier Quad Monitor Stand
Start Rating
  • Are the static columns manually height adjustable?

    Static columns are meant to be set to the desired height of use and left there. If you are looking for something that is instantly height adjustable, either for a sit-stand workstation or one that adjusts to the height of multiple users, the motorized column will likely suit your needs.
